SAFETY SWITCH GREY 6P 125A H

Safety switches 6-poles with auxiliary switch

Safety switches polycarbonate with auxiliary switch Safety switch grey 6-poles 125A with auxilliary
E-number
E3135759
Article number
110128
Support
Standard EN60947-3
Housing material Polycarbonate
Color Grey
Number of poles 6
Mounting method Wall mounting
Isolation voltage [V] 690V
Auxiliary contact Yes
Name SAFETY SWITCH GREY 6P 125A H
E-number E3135759
Article number 110128
RAL-number RAL7035
Connection PE [pcs] 12+11
Power[kW] 55kW
Rated current AC23 400V [A] 125A
Degree of protection [IP] IP65
Connection N [mm²] 70mm²
Connection area Max 70mm²
NetProductWeight 10.23
EngineerWidth 380
EngineerHeight 560
EngineerDepth 240

More variants of Safety switches 6-poles with auxiliary switch

E-number Article number Type designation RAL-number Connection PE [pcs] Power[kW] Rated current AC23 400V [A] Degree of protection [IP] Connection N [mm²] Connection PE [mm²] Connection area NetProductWeight EngineerWidth EngineerHeight EngineerDepth
SAFETY SWITCH GREY 6P 80A AUX E3135758 110127 RAL7035 12+11 45kW 80A IP65 70mm² Max 70mm² 3.82 280 380 171
SAFETY SWITCH GREY 6P 125A H E3135759 110128 RAL7035 12+11 55kW 125A IP65 70mm² Max 70mm² 10.23 380 560 240
SWITCH SAFETY 6P 32A GREY AS E3155216 3155216 SBG 632H RAL7035 12+11 15kW 32A IP66 16mm² 16mm² 35 144 190 131
SWITCH SAFETY 6P 40A GREY AS E3155218 3155218 SBG 640H RAL7035 13,9kW 40A IP66 16mm² 12+11 35 144 190 131
SWITCH SAFETY 6P 63A GREY AS E3155220 3155220 SBG 663H 30kW 63A IP66 35mm² 12+11 35 180 255 139
