MCB 10kA 3-poles D-characteristic
Miniature circuit breaker 10kA ideal for industrial and residential applications. It is capable of protecting the system against short-circuit currents up to 10kA. It is equipped with a mounting bracket that allows you to remove or install a miniature circuit-breaker even when the phase busbar is installed and is compatible with all GARO busbars for miniature circuit-breakers. MCB GS D-Characteristic 4A 10kA 3-pole
E-number
E2142949
E2142949
Article number
2142949
2142949
-
MCB D 3P 0,5A 10kA GSE-number
E2142945Article number
2142945 -
MCB D 3P 1A 10kA GSE-number
E2142946Article number
2142946 -
MCB D 3P 1A 10kA GSE-number
E2142948Article number
2142948 -
MCB D 3P 2A 10kA GSE-number
E2142949Article number
2142949 -
MCB D 3P 6A 10kA GSE-number
E2142950Article number
2142950 -
MCB D 3P 10A 10kA GSE-number
E2142951Article number
2142951 -
MCB D 3P 13A 10kA GSE-number
E2142952Article number
2142952 -
MCB D 3P 16A 10kA GSE-number
E2142953Article number
2142953 -
MCB D 3P 20A 10kA GSE-number
E2142954Article number
2142954 -
MCB D 3P 25A 10kA GSE-number
E2142955Article number
2142955 -
MCB D 3P 32A 10kA GSE-number
E2142956Article number
2142956
| Standard | EN60898-1 |
|---|---|
| Short-circuit current [kA] | 10kA |
| Storage temperature [C] | -35C...+55C |
| Operation Temperature [C] | -25C...+55C |
| Frequency [Hz] | 50/60Hz |
| Housing material | Plastic |
| Color | Grey |
| Rated voltage [V AC] | 415 V AC |
| Number of modules | 3 |
| Number of poles | 3 |
| Tightening torque [Nm] | 3,5Nm |
| Tripping characteristics | D |
| Connection type | Screw |
| Wire flexible [mm²] | 1-25mm² |
| Degree of protection [IP] | IP20 |
| NetProductWeight | 0.277 |
| EngineerWidth | 54 |
| EngineerHeight | 90 |
| EngineerDepth | 75 |
| Name | MCB D 3P 2A 10kA GS |
|---|---|
| E-number | E2142949 |
| Article number | 2142949 |
| Type designation | MCB D304 |
| Rated current [A] | 4A |
