Switches 400A
Switch GPI 400A is available in two versions: as a fuse-switch with terminal connection 2 x 95-240 mm² or as fuse-switch with current transformer insert and houses 3 current transformers 600/5A class 0.2 S. Breakers GEB/TPI-S 400A-2 GPI
| Degree of protection [IP] | 23 |
|---|---|
| Rated current [A] | 400 |
| Frequency [Hz] | 50 |
| Standard | EN 61439-4 |
| Rated voltage [V AC] | 400 |
| Rated current AC23 400V [A] | 400 |
| Rated current AC22 400V [A] | 400 |
| Name | GEB/TPI-S 400A BREAKER GPI |
|---|---|
| Article number | 352872 |
| Type designation | GEB/TPI-S 400 |
| Materials | Hot dip galvanized |
| Colour | Grey |
| Netweight [kg] | 14 |
| Supply voltage [VAC] | 400 |
| Modules [pcs] | 6 |
| Fuse size | EB 400A reglerbar ner till 160A |
| Type of switch | Effektbrytare elektronisk |
| Integrated current transformers | Yes |
| Type of current transformers | 630/5A klass 0,2S |
| fielddefinition.productarea.effektbrytarekarakteristik.name | Reglerbar 1-7 |
| Number of modules GPI | 6 |
