Safety switches aluminium EMC 3-pole 63A
Safety switches aluminium Safety switch 3-pole 16A made of aluminium. Safety switch 3-pole 63A made of aluminium. EMC performance IP66
| Type designation | GKUA363U1VEMC |
|---|---|
| Standard | EN60947-3 |
| Housing material | Aluminium |
| Color | Grey |
| Number of poles | 3P |
| Mounting method | Wall mounting |
| RAL-number | RAL7035 |
| Power[kW] | 30kW |
| Isolation voltage [V] | 690V AC |
| Connection Cu/Al | 35mm² Cu |
| Rated current AC23 400V [A] | 63A |
| Degree of protection [IP] | IP66 |
| Connection PE [mm²] | 35mm² |
| Connection area | 35 |
| Auxiliary contact | Yes |
| Name | SWITCH SAFETY 3P 63A AL EMC |
|---|---|
| E-number | E3134204 |
| Article number | 107628 |
