SOCKET SLOPING 4P 32A 10h

Flanged sockets Basic with sloping mounting plate 32A IP44

Basic, our standard range with a screw function.Socket 32A for recess mounting with straight small mounting plate. Supplied including seal. Socket sloping basic 4-poles 32A 10h
E-number
2425051
Article number
2425051
Support
Wire flexible [mm²] 2,5-6
Rated current [A] 32
Degree of protection [IP] 44
Standard Class 1 EN 60044-8
Package size [pcs] 10
Width [mm] 80
Height [mm] 97
Materials Plastic
Location Recessed
Function Basic
Wire solid [mm²] 2,5-10
Name SOCKET SLOPING 4P 32A 10h
E-number 2425051
Article number 2425051
Type designation UIS 332-10 S
Colour Green
Frequency [Hz] 100-300
Rated voltage [V AC] >50
Netweight [kg] 0.19
Depth [mm] 102
No.of Poles [pcs] 4/3P+E
Position of earth [h] 10
RAL-nummer RAL6010

More variants of Flanged sockets Basic with sloping mounting plate 32A IP44

E-number Article number Type designation Colour Frequency [Hz] Rated voltage [V AC] Netweight [kg] Depth [mm] No.of Poles [pcs] Position of earth [h] RAL-nummer
SOCKET SLOPING 3P 32A 2h 2425039 2425039 UIS 232-2 S Green >300-500 >50 0.17 102 3/2P+E 2 RAL6010
SOCKET SLOPING 3P 32A 4h 2425040 2425040 UIS 232-4 S Yellow 50/60 100-130 0.17 102 3/2P+E 4 RAL1023
SOCKET SLOPING 3P 32A 6h 2425041 2425041 UIS 232-6 S Blue 50/60 200-250 0.17 102 3/2P+E 6 RAL5017
SOCKET SLOPING 3P 32A 7h 2425042 2425042 UIS 232-7 S Black 50/60 480-500 0.17 102 3/2P+E 7 RAL9005
SOCKET SLOPING 3P 32A 9h 2425043 2425043 UIS 232-9 S Red 50/60 380-415 0.17 102 3/2P+E 9 RAL3000
SOCKET SLOPING 3P 32A 12h 2425044 2425044 UIS 232-12 S Grey 50/60 Matning fr.isolertransf. 0.17 102 3/2P+E 12 RAL7046
SOCKET SLOPING 4P 32A 2h 2425045 2425045 UIS 332-2 S Green >300-500 >50 0.19 102 4/3P+E 2 RAL6010
SOCKET SLOPING 4P 32A 3h 2425046 2425046 UIS 332-3 S Red 50/60 380-440 0.19 102 4/3P+E 3 RAL3000
SOCKET SLOPING 4P 32A 4h 2425047 2425047 UIS 332-4 S Yellow 50/60 100-130 0.19 102 4/3P+E 4 RAL1023
SOCKET SLOPING 4P 32A 6h 2425048 2425048 UIS 332-6 S Red 50/60 400 0.19 102 4/3P+E 6 RAL3000
SOCKET SLOPING 4P 32A 7h 2425049 2425049 UIS 332-7 S Black 50/60 480-500 0.19 102 4/3P+E 7 RAL9005
SOCKET SLOPING 4P 32A 9h 2425050 2425050 UIS 332-9 S Blue 50/60 230 0.19 102 4/3P+E 9 RAL5017
SOCKET SLOPING 4P 32A 10h 2425051 2425051 UIS 332-10 S Green 100-300 >50 0.19 102 4/3P+E 10 RAL6010
SOCKET SLOPING 4P 32A 11h 2425052 2425052 UIS 332-11 S Red 60 440-460 0.19 102 4/3P+E 11 RAL3000
SOCKET SLOPING 5P 32A 2h 2425053 2425053 UIS 432-2 S Green >300-500 >50 0.21 102 5/3PN+E 2 RAL6010
SOCKET SLOPING 5P 32A 3h 2425054 2425054 UIS 432-3 S Red 50/60 380-440 0.21 103 5/3PN+E 3 RAL3000
SOCKET SLOPING 5P 32A 4h 2425055 2425055 UIS 432-4 S Yellow 50/60 100-130 0.21 103 5/3PN+E 4 RAL1023
SOCKET SLOPING 5P 32A 6h 2425056 2425056 UIS 432-6 S Red 50/60 230/400 0.21 103 5/3PN+E 6 RAL3000
SOCKET SLOPING 5P 32A 7h 2425057 2425057 UIS 432-7 S Black 50/60 480-500 0.21 103 5/3PN+E 7 RAL9005
SOCKET SLOPING 5P 32A 9h 2425058 2425058 UIS 432-9 S Blue 50/60 208-250 0.21 103 5/3PN+E 9 RAL5017
SOCKET SLOPING 5P 32A 11h 2425059 2425059 UIS 432-11 S Red 60 440-460 0.21 103 5/3PN+E 11 RAL3000
