Entity Pro outlet single
Article number
354205
354205
| Standard | EN61851-1, IEC 62955, ISO15118, EN61008-1, EN60898-1 |
|---|---|
| Short-circuit current [kA] | 10kA |
| Storage temperature [C] | -40C...+40C |
| Operation Temperature [C] | -40C...+40C |
| Frequency [Hz] | 50Hz |
| Housing material | Plastic |
| Color | Black |
| Rated current [A] | 32A |
| Rated voltage [V AC] | 230/400V AC |
| Mounting method | Wall mounting |
| Modelltype | Entity Pro |
| Lock | Yes |
| AC/DC output 1 | Type 2 Outlet |
| Local load balance | Yes |
| RAL-number | RAL9011 |
| Dynamic load management | Yes |
| Degree of protection [IP] | IP54 |
| Impact strength [IK] | IK10 |
| EngineerWidth | 240 |
| EngineerHeight | 340 |
| EngineerDepth | 150 |
| Name | WALLBOX ENTITY PRO 7 PME |
|---|---|
| Article number | 354205 |
| Type designation | EPCSO00132FIGIP |
| Energymeter | Built-in meter |
| Phases [PH] | 1PH |
| Energymeter MID | 0 |
| Networkable LAN | 0 |
| Networkable WiFi | 0 |
| Power per charging point [kW] | 7,4kW |
| Configurated APP | 0 |
| Charging current [A] | 0-20 |
| NetProductWeight | 4 |
