Metalcabinets KMN without bottombox
GARO’s metal cabinets, which are a combination of DIN and media metal cabinets, which can be flush mounted in the wall as well as surface mounted, delivered without a bottom tray. The media section is positioned above or under the DIN section. The number of modules in the DIN section is 20 on each row. Mounting panel with space for 24 x RJ45 jacks (14 x 20 mm per/hole). In addition, there is an extra RJ45 on a separate line. Four wall sockets are mounted on delivery, but two additional power outlets can be Consumer unit metal combi flush mounted 1row 20modules media above without bottombox.
-
CONSUMER UNIT F 1R20M U WOB COE-number
E2290028Article number
356033 -
CONSUMER UNIT F 2R40M U WOB COE-number
E2290029Article number
356034 -
CONSUMER UNIT F 3R60M U WOB COE-number
E2290030Article number
356035 -
CONSUMER UNIT F 2R40M D WOB COE-number
E2290032Article number
356041 -
CONSUMER UNIT F 3R60M D WOB COE-number
E2290033Article number
356042
| Standard | EN61439-3 |
|---|---|
| Frequency [Hz] | 50Hz |
| Housing material | Sheet steel |
| Color | White |
| Rated voltage [V AC] | 400V AC |
| Mounting method | Surface mounted/recessed mounted |
| Lock | No |
| RAL-number | RAL9010 |
| DIN-rail | Yes |
| Mountingplate | Yes |
| Recessed depth [mm] | 107mm |
| Recessed width [mm] | 395mm |
| Type of door | Single |
| Number of Schuko[pcs] | 2pcs |
| RJ45 [pcs] | 21pcs Keystone (14x20mm/hole) |
| Degree of protection [IP] | IP30 |
| Transparent cover/door | No |
| Bottombox | No |
| EngineerWidth | 418 |
| EngineerDepth | 140 |
| Name | CONSUMER UNIT F 1R20M U WOB CO |
|---|---|
| E-number | E2290028 |
| Article number | 356033 |
| Type designation | KMNU 20-1/4 |
| Rated current [A] | 40A |
| Number of modules | 20 |
| Modelltype | KMN |
| Connection N [pcs] | 16 |
| Connection PE [pcs] | 16 |
| Further feeding [A] | Further feeding 63A |
| Number of rows | 1 |
| Recessed height [mm] | 718mm |
| NetProductWeight | 7.3 |
| EngineerHeight | 747 |
