RCBO C 2P 6A 6kA U

Earth leakage circuit breaker (RCBO) 6kA 2-poles C-characteristic 1-module

Earth leakage circuit breaker (RCBO) 6kA 2-poles C-characteristic 1-module Earth leakage circuit breaker (RCBO) GC C-characteristic 2-poles 6A 6kA 1-module
E-number
E2163337
Article number
111372
Support
Standard EN61009-1
Storage temperature [C] -35C...+55C
Operation Temperature [C] -25C...+55C
Frequency [Hz] 50/60Hz
Housing material Plastic
Color Grey
Rated voltage [V AC] 230/400V AC
Number of poles 2
Tightening torque [Nm] 2,5Nm
Tripping characteristics C
Connection type Screw
Wire flexible [mm²] 1,5-2,5mm²
Mounting method DIN-rail
Degree of protection [IP] IP20
Sensitivity[mA] 30mA
Leakage current type A
Claim prefuse [A] 100A
NetProductWeight 0.11
EngineerWidth 18
EngineerHeight 89
EngineerDepth 77
Name RCBO C 2P 6A 6kA U
E-number E2163337
Article number 111372
Type designation RCBO C2P 6A 6kA U GC
Short-circuit current [kA] 6kA
Rated current [A] 6A
Number of modules 1

More variants of Earth leakage circuit breaker (RCBO) 6kA 2-poles C-characteristic 1-module

E-number Article number Type designation Short-circuit current [kA] Rated current [A] Number of modules
RCBO C 2P 6A 6kA U E2163337 111372 RCBO C2P 6A 6kA U GC 6kA 6A 1
RCBO C 2P 10A 6kA U E2163338 111373 RCBO C2P 10A 6kA U GC 10kA 13A 1
RCBO C 2P 13A 6kA U E2163339 111374 RCBO C2P 13A 6kA U GC 6kA 13A 1
RCBO C 2P 16A 6kA U E2163340 111375 RCBO C2P 16A 6kA U GC 6kA 13A 3
RCBO C 2P 20A 6kA U E2163341 111376 RCBO C2P 20A 6kA U GC 10kA 13A 2
RCBO C 2P 25A 6kA U E2163342 111377 RCBO C2P 25A 6kA U GC 10kA 6A 1
