Staircase cabinets 63A schuko/CEE
Staircase panel 63A with CCE input in different equipment variants for easy handling, placement on the floor or wall mounted. Staircase cabinet 63A 4xRCCB 6xschuko 2x16A outlet 2x32A outlet 1x63A outlet
E-number
E2469115
E2469115
Article number
2469115
2469115
| Type designation | U GTC463-6/00/12206-31 |
|---|---|
| Standard | EN61439-4 |
| Short-circuit current [kA] | 17kA |
| Frequency [Hz] | 50Hz |
| Housing material | Aluminium |
| Color | Red |
| Rated current [A] | 63A |
| Rated voltage [V AC] | 230/400V AC |
| CEE socket outlet 16A | 2pcs 5P 16A 230/400V |
| Number of MCB 1P (1) | 3pcs C113 |
| Number of MCB 1P (2) | 2pcs C332 |
| Number of Schuko[pcs] | 6pcs |
| Number of RCCB [pcs] 1 | 1pcs 4P 63A |
| CEE socket outlet 32A | 2pcs 5P 32A 230/400V |
| Number of RCCB [pcs] 2 | 1pcs 4P 63A 300mA |
| Degree of protection [IP] | IP44 |
| NetProductWeight | 13 |
| EngineerWidth | 540 |
| EngineerHeight | 490 |
| EngineerDepth | 250 |
| Name | STAIRCASE CAB 63A 4xRCB |
|---|---|
| E-number | E2469115 |
| Article number | 2469115 |
