Sockets wall Basic Schuko 16A IP44
Basic, our standard range with a screw function. Socket 32A suitable for wall mounting and engine mounting with cable connectivity from both the top and bottom. If the wall socket is mounted outdoors, or if it is likely that it is used to feed portable equipment outdoors, it must be preceded by an all-pole residual current device with a maximum of 30 mA rated tripping current. Wall socket basic with french schuko 3-poles 16A 6h
E-number
E2424759
E2424759
Article number
2424759
2424759
-
WALLSOCKET 3P 16A 6h SCHUKOE-number
E2424758Article number
2424758 -
WALLSOCKET 3P 16A 6h SCHUKO FRE-number
E2424759Article number
2424759 -
WALLSOCKET 3P 16A 6h SCHUKO GBE-number
E2424760Article number
2424760 -
WALLSOCKET 4P 16A 9h SCH SWEE-number
E2424761Article number
2424761 -
WALLSOCKET 5P 16A 6h SCH SWEE-number
E2424763Article number
2424763 -
WALLSOCKET 5P 16A 6h SCH FRE-number
E2424764Article number
2424764 -
WALLSOCKET 5P 16A 6h SCH DKE-number
E2424765Article number
2424765
| Housing material | Plastic |
|---|---|
| Rated current [A] | 16A |
| Wire flexible [mm²] | 1-2,5mm² |
| Modelltype | Basic |
| Wire solid [mm²] | 1-4mm² |
| Degree of protection [IP] | IP44 |
| Name | WALLSOCKET 3P 16A 6h SCHUKO FR |
|---|---|
| E-number | E2424759 |
| Article number | 2424759 |
| Type designation | UI 216-6 S+RU/UIFF |
| Color | Blue |
| Rated voltage [V AC] | 200-250V AC |
| Number of poles | 3/2P+E |
| RAL-number | RAL5017 |
| Clock hour position [h] | 6h |
| NetProductWeight | 0.36 |
| EngineerWidth | 80 |
| EngineerHeight | 175 |
| EngineerDepth | 127 |
