Phase inverter 32A IP44
GARO’s phase shifters 32A Basic, which are easily operated with a screwdriver. A convenient solution to a common problem with incorrect phase sequence in installations. Phase inverters basic 5-poles 32A 6h
| Type designation | FV 432-6 S |
|---|---|
| Materials | Plastic |
| Standard | EN60309-2 |
| Frequency [Hz] | 50/60Hz |
| Color | Red |
| Rated current [A] | 32A |
| Rated voltage [V AC] | 230/400V AC |
| Number of poles | 5/3P+N+E |
| Connection type | Screwed terminal |
| Wire flexible [mm²] | 2,5-6mm² |
| Modelltype | Basic |
| RAL-number | RAL3000 |
| Clock hour position [h] | 6h |
| Phase inverter | Yes |
| Plug angle | Straight |
| Pin/Sleeve | Pin |
| Degree of protection [IP] | IP44 |
| NetProductWeight | 0.24 |
| EngineerWidth | 190 |
| EngineerHeight | 170 |
| EngineerDepth | 290 |
| Name | PHASE INVERTER 5P 32A 6h |
|---|---|
| E-number | E2424631 |
| Article number | 2424631 |
