Gbox without RCCB IP44
GARO’s socket box, G-box equipped according to the characteristics below. All G-boxes are equipped with terminal blocks for connecting Cu 2//35 mm². For Al-cable connections, max 1//50 mm², thrust washers are used between the Al and Cu cables. The plastic material in the G-box is environmentally friendly and chemical-resistant. Outlet box equipped 01205 Gbox
E-number
E2468804
E2468804
Article number
2468804
2468804
| Type designation | 01205 |
|---|---|
| Standard | EN61439-4 |
| Short-circuit current [kA] | 10kA |
| Color | Grey |
| Rated current [A] | 63A |
| Rated voltage [V AC] | 230/400V AC |
| CEE socket outlet 16A | 2pcs 5P 16A 230/400V |
| Number of MCB 1P (1) | 3pcs C113 |
| Number of MCB 3P (1) | 1pcs C316 |
| Number of MCB 3P (2) | 1pcs C332 |
| Number of RCCB [pcs] 1 | No |
| CEE socket outlet 32A | 1pcs 5P 32A 230/400V |
| Number of RCBO [pcs] | No |
| Degree of protection [IP] | IP44 |
| Name | OUTLETBOX 01205 GBOX |
|---|---|
| E-number | E2468804 |
| Article number | 2468804 |
