Twin Fixed cable without Wifi

GAROs wallbox with two charging points, without Wifi. Can be built to the desired system through group formation, based on the master unit with Wifi card to which simpler charging boxes can be connected. Each charging point is protected with DC fault protection and RCBO A according to international standards. Load balancing automatically reduces the vehicle's charging current and minimizes the risk of the main fuse tripping. Complete with GARO Modbus energy meter in the power station for activation of load balancing. Wallbox 2pcs type2 with fixed cable 7,4kW RCCB-A DC-fault protection with meter
E-number
2480303
Article number
353681
Rated current [A] 32
Meter Yes
Materials Aluminium
Colour Black
Rated voltage [V AC] 230/400
Cable [m] 4
Package size [pcs] 1
Standard EN 61851-1 IEC 61439-7 AEVCS
Width [mm] 377
Height [mm] 660
Depth [mm] 213
Frequency [Hz] 50
Temperature range [C] -25...+40
Mounting method Wall mounting
Degree of protection [IP] 44
Storage temperature [C] -40...+50
RFID No
Impact strength IK10
RCCB/RCBO RCCB A DC fault protection
Charging current [A] 6, 10, 13, 16, 20, 25, 32
Locks Yes
Name WALLBOX 2FCT2 7,4kW DCM-A
E-number 2480303
Article number 353681
Type designation GTB-DCM-T274FC-A
AC/DC output Type2 fixed cable
AC/DC output Type2 fixed cable
Netweight [kg] 14
Phases 1
Power outlet [kW] 7,4

More variants of Twin Fixed cable without Wifi

E-number Article number Type designation AC/DC output AC/DC output Netweight [kg] Phases Power outlet [kW]
WALLBOX 2FCT2 11kW DCM-A 2480301 353679 GTB-DCM-T211FC-A Type2 fixed cable Type2 fixed cable 15 3 11
WALLBOX 2FCT2 7,4kW DCM-A 2480303 353681 GTB-DCM-T274FC-A Type2 fixed cable Type2 fixed cable 14 1 7,4
