Twin+ Fixed cable MC
Wallbox with two charging points. Each charging point is individually protected by DC fault protection, earth fault circuit breaker and integrated fuse, and is equipped with MID-approved energy meter. TWIN + supports OCPP communication. Connection is via 4G. TWIN + can be load balanced individually or in groups against external meters. Wallbox 2 type2 fixed cable 11kW connectable via 4G, with meter and RFID.
| Type designation | GTB-B-DCM-T211FC-A-R-MC |
|---|---|
| Rated current [A] | 32 |
| Meter | Yes |
| Materials | Aluminium |
| Colour | Black |
| Rated voltage [V AC] | 230/400 |
| Cable [m] | 4 |
| Package size [pcs] | 1 |
| Standard | EN 61851-1 IEC 61439-7 AEVCS |
| Netweight [kg] | 18 |
| Width [mm] | 277 |
| Height [mm] | 660 |
| Depth [mm] | 213 |
| Frequency [Hz] | 50 |
| Temperature range [C] | -25C...+40C |
| Mounting method | Wall mounting |
| Degree of protection [IP] | 44 |
| Storage temperature [C] | +40C...+50C |
| Phases | 3 |
| RFID | Yes |
| Impact strength | IK10 |
| Communication | Mobile Com |
| RCCB/RCBO | RCCB A DC fault protection |
| Power outlet [kW] | 11 |
| Locks | Yes |
| DC-fault protection | Yes |
| Name | WALLBOX TWIN+ T2FC 11kW M R MC |
|---|---|
| E-number | 2480318 |
| Article number | 353983 |
| AC/DC output | Type2 fixed cable |
| AC/DC output | Type2 fixed cable |
