CASTRA camping post wifi

CASTRA camping posts is a combined charge and outlet post for the camping environment. The post is equipped with a type2 car chargeoutlet and a CEE-outlet on each side that is load balanced for desired power outtake. CASTRA can be mounted on 60mm pipe post or on ground stand. Camping post CASTRA 2pcs type2EV outlet 2,3kW, 2pcs CEE-outlet 10A, load balance and Wifi.
E-number
2480384
Article number
353915
Materials Aluminium
Colour Grey
Standard IEC 61851-1 IEC TS 61439-7
Netweight [kg] 26.40
Width [mm] 375
Height [mm] 1400
Depth [mm] 208
Degree of protection [IP] 44
Frequency [Hz] 50
Flanged socket outlet 2 pcs 16A 216-6 230V
Rated voltage [V AC] 230/400
Short-circuit current [kA] 10
RFID Yes
Impact strength IK10
Temperature range [C] -25...+40
Storage temperature [C] -35...+55
Display Yes/No No
Cable [m] Not included
RCCB/RCBO 4 pcs RCBO type A
WIFI Yes
Mounting method Floor fastening
Meter Yes
Kommunikation Yes
Name CAMPPOLE CLS1 T2EV 2,3kW A W
E-number 2480384
Article number 353915
Type designation CLS1-DCM-W-T223WO-A
Rated current [A] 10
Phases 3
AC/DC output Type2 outlet
AC/DC output Type2 outlet
Power outlet [kW] 2,3

More variants of CASTRA camping post wifi

E-number Article number Type designation Rated current [A] Phases AC/DC output AC/DC output Power outlet [kW]
CAMPPOLE CLS1 T2EV 2,3kW A W 2480384 353915 CLS1-DCM-W-T223WO-A 10 3 Type2 outlet Type2 outlet 2,3
CAMPPOLE CLS1 T2EV 3,7kW A W 2480385 353916 CLS1-DCM-W-T237WO-A 32 1 Type2 outlet Type2 outlet 3,7
