Measurement devices flex.wire 25A
Mains distribution assembly 25A (HC25) is normally used for the construction of small houses and detached houses, etc. The distribution assembly is equipped with sockets 13-32A which are preceded by residual current devices and miniature circuit breakers. Equipped with a hot-dip galvanized stand and lockable door. Temporary power meter unit 35A RCCB
| Type designation | |
|---|---|
| Materials | Sheet metal |
| Degree of protection [IP] | 44 |
| Colour | Red |
| Netweight [kg] | 31 |
| Frequency [Hz] | 50 |
| Standard | EN 61439-4 |
| Width [mm] | 525 |
| Height [mm] | 1100 |
| Depth [mm] | 650 |
| Flanged socket outlet | 1 pcs 16A 3P+N+E 230/400V |
| Rated voltage [V AC] | 230/400 |
| Package size [pcs] | 1 |
| Flanged socket outlet | 1 pcs 32A 3P+N+E 230/400V |
| Short-circuit current [kA] | 17 |
| RCCB | 1 pcs 40A/4P |
| MCB | 2 pcs C113 |
| MCB | 1 pcs C316 |
| Schuko [pcs] | 3 |
| Connection [mm²] | 10-50 |
| Space for meters [pcs] | 1 |
| Name | TEMP POWER MET UNIT 35A RCCB |
|---|---|
| Article number | 353259 |
| Rated current [A] | 35 |
