Streetlight cabinet astro 2 groups

Complete street light cabinet for 2 outgoing groups equipped with a wooden board for meters of consumption. The lighting is activated via internal control with astronomical timer where setting of location / coordinates automatically adjusts and controls after the sun rises and sets Street light cabinet with 2 outgoing DII groups. Controlled by internal astronomical timer
E-number
0731490
Article number
354541
Type designation GCL-2DAU
Rated current [A] 63
Poles 4
Rated voltage [V AC] 400
Frequency [Hz] 50
Degree of protection [IP] 34D
Colour Grey
Standard IEC 61439-1, -5
Package size [pcs] 1
Width [mm] 326
Height [mm] 1550
Depth [mm] 240
Netweight [kg] 44.90
Materials Stål
Short-circuit current [kA] 25
Fuse size 2xDll
Incoming terminal Cu [mm²] 50 Al/Cu
Mounting method Ground mounted
Impact strength IK10
Outgoing terminal [mm²] 16 Cu
Light relay No
Time switch Yes
Measurement Yes
Contactor [A] 40
Name STREET LIGHT CABIN 2 GRP ASTRO
E-number 0731490
Article number 354541

Accessories for Streetlight cabinet astro 2 groups

Name E-number Article number Type designation Description
ANGLE BRACKET BASE ANGLE BRACKET BASE 0731377 354610 GDC-GB Angle bracket base
PLATE BASE 472MM PLATE BASE 472MM 0731378 354611 GDC-GP472 Baseplate 472mm
PLATE BASE 322MM PLATE BASE 322MM 0731379 354612 GDC-GP322 Baseplate 322mm
