Plugs basic 32A IP44 7P
Plugs basic 32A IP44 7P Plug basic 7-poles 32A 6h
E-number
2425909
2425909
Article number
107749
107749
Type designation | P 732-6S |
---|---|
Rated current [A] | 32 |
No.of Poles [pcs] | 7P |
Rated voltage [V AC] | 400 |
Frequency [Hz] | 50/60 |
Degree of protection [IP] | 44 |
Colour | Red |
Standard | Class 1 EN 60044-8 |
Width [mm] | 70 |
Height [mm] | 156 |
Depth [mm] | 70 |
Netweight [kg] | 0.28 |
Materials | Plastic |
Function | Basic |
Position of earth [h] | 6 |
RAL-nummer | RAL3000 |
Name | PLUG 7P 32A 6h |
---|---|
E-number | 2425909 |
Article number | 107749 |
