RCBO C 2P 16A 6kA U

RCBO 6kA 2-pole C-characteristics 1-mod

Garo 1-module RCBO is an electronic version that is ideal when space is limited as it is only 1 module wide. The design is suitable for the Swedish outdoor climate as it is tested and approved for -35 degrees. Earth leakage circuit breaker (RCBO) GC C-characteristic 2-poles 16A 6kA 1-module
E-number
2163340
Article number
111375
Support
Poles 2
Rated voltage [V AC] 230/400
Frequency [Hz] 50/60
Degree of protection [IP] 20
Colour Grey
Storage temperature [C] -35...+55
Standard EN 61009-1
Package size [pcs] 1
Width [mm] 18
Height [mm] 89
Netweight [kg] 0.11
Materials Plastic
Rated short-circuit cap. [kA] 6
Connection type Screw
Tripping characteristics C
Sensitivity [mA] 30
Leakage current A
Name RCBO C 2P 16A 6kA U
E-number 2163340
Article number 111375
Type designation RCBO C2P 16A 6kA U GC
Rated current [A] 6
Wire flexible [mm²] 1,5-2,5
Tightening torque [Nm] 2,5
Temperature range [C] -25...+55
Modules [pcs] 3
Depth [mm] 177
Claim prefuse [A] 100

More variants of RCBO 6kA 2-pole C-characteristics 1-mod

E-number Article number Type designation Rated current [A] Wire flexible [mm²] Tightening torque [Nm] Temperature range [C] Modules [pcs] Depth [mm] Claim prefuse [A]
RCBO C 2P 6A 6kA U 2163337 111372 RCBO C2P 6A 6kA U GC 6 1,5-2,5 2,5 -25...+55 1 77 100
RCBO C 2P 10A 6kA U 2163338 111373 RCBO C2P 10A 6kA U GC 6 1,5-2,5 2,5 -25...+55 1 77 100
RCBO C 2P 13A 6kA U 2163339 111374 RCBO C2P 13A 6kA U GC 6 1,5-2,5 2,5 -25...+55 1 77 100
RCBO C 2P 16A 6kA U 2163340 111375 RCBO C2P 16A 6kA U GC 6 1,5-2,5 2,5 -25...+55 3 177 100
RCBO C 2P 20A 6kA U 2163341 111376 RCBO C2P 20A 6kA U GC 6 1,5-2,5 2,5 -25...+55 2 77 100
RCBO C 2P 25A 6kA U 2163342 111377 RCBO C2P 25A 6kA U GC 6 1,5-2,5 2,5 -25...+55 1 77 100
