More variants of Busbars

E-number Article number Type designation Modules [pcs] Phases Netweight [kg] Width [mm] Height [mm] Depth [mm] connec conductor cross-sec[mm²]
BUSBARS 3P 57M 10 108469 FS 357 57 3 0.43 10
BUSBARS 3P 6M/10 2142370 110387 GBB 3-06-10 6 3 0.10 15.50 28.50 106 10
BUSBARS 3P 9M/10 2142371 110390 GBB 3-09-10 9 3 0.07 45 28.50 160 10
BUSBARS 3P 13M/10 2142372 110394 GBB 3-13-10 13 3 0.16 15.50 25.50 230 10
BUSBARS 3P 14M/10 2142373 110395 GBB 3-14-10 14 3 0.14 15.50 28.50 250 10
BUSBARS 3P 20M/10 2142374 110401 GBB 3-20-10 20 3 0.20 15.50 28.50 355 10
BUSBARS 3P 21M/10 2142375 110402 GBB 3-21-10 21 3 0.21 15.50 28.50 375 10
BUSBARS 3P 25M/10 2142376 110405 GBB 3-25-10 25 3 0.24 15.50 28.50 448 10
BUSBARS 3P 57M/10 2142377 110406 GBB 3-57-10 57 3 0.85 15.50 28.50 1016 10
BUSBARS 3P 57M/16 2142378 110410 GBB 3-57-16 57 3 1.05 15.80 30.50 1016 16
BUSBARS 3P+N 57M/16 2142379 110411 GBB 3N-57-16 57 3 0.93 20.80 30.50 1016 16
BUSBARS 1P 57M/10 2142380 110414 GBB 1-57-10 57 1 0.44 15.10 16.50 1016 10
BUSBARS 1P+N 57M/16 2142381 110415 GBB 1N-57-16 57 1 0.88 20.80 30.50 1016 16
BUSBARS 1M 3-PHASE 2142002 352153 FS 412-L 12 3 0.09 218 19 29
