Plastic cabinets IP31 equipped
GARO’s plastic distribution cabinet for surface mounting, pre-equipped. The boards is manufactured entirely of metal and fitted with snap-in terminal blocks. The entire interior is held in place by a simple bracket, which opens out to 90° for installation or adjustment. This provides a comfortable workspace and is a great help during final assembly of the outgoing cables. This contributes to safeguarding the complete cabinet in terms of the risk of flashover and the onset of arcing between poorly connected Consumer unit plastic surface mounted 1row 13modules equipped
-
CONSUMER U PLAST SURF 1R13MEQE-number
E2178976Article number
2178976 -
CONSUMER U PLAST SURF 1R13MEQ6E-number
E2178977Article number
2178977 -
CONSUMER U PLAST SURF 2R26MEQE-number
E2178978Article number
2178978 -
CONSUMER U PLAST SURF 2R26MEQ6E-number
E2178979Article number
2178979 -
CONSUMER U PLAST SURF 3R39MEQE-number
E2178980Article number
2178980 -
CONSUMER U PLAST SU3R39MEQ6E-number
E2178981Article number
2178981 -
CONSUMER U PLAST SU2R26M EQ QE-number
E2200265Article number
352136
| Standard | EN61439-3 |
|---|---|
| Frequency [Hz] | 50Hz |
| Housing material | Plastic |
| Color | White |
| Mounting method | Surface mounted |
| Modelltype | NUP |
| RAL-number | RAL9010 |
| Further feeding [A] | Further feeding 63A |
| Degree of protection [IP] | IP31 |
| EngineerWidth | 300 |
| EngineerDepth | 125 |
| Name | CONSUMER U PLAST SURF 1R13MEQ |
|---|---|
| E-number | E2178976 |
| Article number | 2178976 |
| Type designation | NUP 113 |
| Short-circuit current [kA] | 10kA |
| Rated current [A] | 35A |
| Rated voltage [V AC] | 400V AC |
| Number of modules | 13 |
| Number of rows | 1 |
| Switch [pcs] | 3x40A |
| Number of MCB 1P (1) | 2pcs C110 |
| Number of MCB 1P (2) | 3pcs C116 |
| Number of RCCB [pcs] 1 | 1pcs 4P 40A |
| NetProductWeight | 2.2 |
| EngineerHeight | 245 |
