Metal cabinets IP30 with bottombox
GARO’s metal distribution cabinets for recess mounting in walls. All metal cabinets are equipped with snap-in terminal blocks. The entire interior is held in place by a simple bracket, which opens out to 90° for installation or adjustment. This provides a comfortable workspace for final assembly of the outgoing cables. The depth behind the DIN rails is 23 mm in the metal enclosure. The cabinets are always supplied with a door that can be hung as needed. The doors are prepared for the possible installation o CONSUMER UNIT METAL RECED 3R75M W BOX
-
CONSUMER UNIT METAL RECED 1R14M W BOXE-number
E2290001Article number
356000 -
CONSUMER UNIT METAL RECED 2R28M W BOXE-number
E2290002Article number
356002 -
CONSUMER UNIT METAL RECED 3R42M W BOXE-number
E2290003Article number
356004 -
CONSUMER UNIT METAL RECED 1R20M W BOXE-number
E2290004Article number
356006 -
CONSUMER UNIT METAL RECED 2R40M W BOXE-number
E2290005Article number
356008 -
CONSUMER UNIT METAL RECED 3R60M W BOXE-number
E2290006Article number
356010 -
CONSUMER UNIT METAL RECED 4R80M W BOXE-number
E2290007Article number
356012 -
CONSUMER UNIT METAL RECED 5R100M W BOXE-number
E2290008Article number
356014 -
CONSUMER UNIT METAL RECED 3R75M W BOXE-number
E2290009Article number
356016
| Standard | EN61439-3 |
|---|---|
| Short-circuit current [kA] | 10kA |
| Frequency [Hz] | 50Hz |
| Housing material | Sheet metal |
| Color | White |
| Rated voltage [V AC] | 400V AC |
| Mounting method | Flush mounted |
| Modelltype | NIM |
| Lock | No |
| RAL-number | RAL9010 |
| DIN-rail | Yes |
| Further feeding [A] | Further feeding 63A |
| Mountingplate | No |
| Recessed depth [mm] | 82mm |
| Type of door | Single |
| Degree of protection [IP] | IP30 |
| Bottombox | Yes |
| EngineerDepth | 115 |
| Name | CONSUMER UNIT METAL RECED 3R75M W BOX |
|---|---|
| E-number | E2290009 |
| Article number | 356016 |
| Type designation | NIM 75-3 |
| Rated current [A] | 50A |
| Number of modules | 75 |
| Connection N [pcs] | 11+10+11+11 |
| Connection PE [pcs] | 25+25 |
| Number of rows | 3 |
| Recessed height [mm] | 968mm |
| Recessed width [mm] | 492mm |
| NetProductWeight | 9 |
| EngineerWidth | 515 |
| EngineerHeight | 547 |
